QElectroTech is a free software to create electric diagrams. QElectroTech is under GNU/GPL license. It is currently available for Windows, Mac OS and Linux.



Apps similar to Wiring Diagram include QElectroTech, which is free and open source. Other options are sPlan, Graphisoft DDScad, EPLAN Electric P8 and WSCAD ELECTRIX. In total there are five CAD Software apps like Wiring Diagram for Windows, Linux and Mac.
QElectroTech is a free software to create electric diagrams. QElectroTech is under GNU/GPL license. It is currently available for Windows, Mac OS and Linux.



sPlan is a software with already many thousands enthusiastic users. You need a software to design your schematic circuit diagrams easy and fast? Then there is no way around sPlan! No matter if you only want to sketch a little circuit diagram or if you need to design a big...

Offers stand-alone calculation, design, and visualization for MEP systems including electrical, plumbing, heating, ventilation, and air conditioning. Enables clash detection, integrated documentation, Open BIM collaboration, and flexible modular packages for projects.



CAE software solution for project planning, documentation and administration of electrotechnical automation projects.




No matter if you are designing piping & instrumentation diagrams, fluid power or electrical schematics, cabinet engineering, building automation or electrical installation – ELECTRIX is the right tool for you.
